Teknik Özellikler

Model
HR900-IIA2
HR1200-IIA2
HR1500-IIA2
General Specifications
Power Supply(V/Hz)
220-240/50
220-240/50
220-240/50
Power(VA)
1500
1500
1900
Power of Blower(W)
AC L=330,M=465,H=735
AC L=330,M=465,H=735
AC 650
Airflow Circulation
70% Downflow,30% Exhaust
70% Downflow,30% Exhaust
70% Downflow,30% Exhaust
Main Filter Typical Efficiency
ULPA ,U15,99.9995%@0.12um
ULPA ,U15,99.9995%@0.12um
ULPA ,U15,99.9995%@0.12um
Exhaust Filter Typical Efficiency
ULPA ,U15,99.9995%@0.12um
HEPA ,H14,99.995%@0.3um
HEPA ,H14,99.995%@0.3um
Exhaust Filter
Single
Single
Single
Downflow Velocity(m/s)
0.33
0.34
0.31
Inflow Velocity(m/s)
0.55
0.55
0.55
Lighting Intensity (Lux)
≥900
≥900
≥900
Sound Level(dB(A))
60
60
62
Dimensions
Net/Gross Weight
kg
290/310
320/339
350/393
Internal Dimensions(W*D*H)
mm
920*620*650
1220*620*650
1520*620*650
External Dimensions(W*D*H) (Width without Armrest)
mm
1080*845(790)*2160
1380*845(790)*2160
1680*845(790)*2160
Support Stand(mm)
680-900mm adjustable height(standard)
680-900mm adjustable height(standard)
680-900mm adjustable height(standard)
Sash Opening(mm)
200(Max 490)
200(Max 490)
200(Max 490)
Container load (20'/40'/40'H)
11/21/21
8/16/16
12/6/2012
Alarm Functions
Alarm
Sound and Flash
Sound and Flash
Sound and Flash
Closing Fan Alarm After Door Opening
Y
Y
Y
Door Ajar
Y
Y
Y
Abnormal Inflow
Y
Y
Y
Abnormal Downflow
Y
Y
Y
Door Open More than Limit
Y
Y
Y
Filter Clogging
Y
Y
Y
Filter Damage
Y
Y
Y
Filter Lifetime Lack
Y
Y
Y
UV light Lifetime Lack
Y
Y
Y
Accessories
UV Lamp
Y
Y
Y
Socket
2 Sockets
2 Sockets
2 Sockets
Valve Port
Standard with 2 Valve Port
Standard with 2 Valve Port
Standard with 2 Valve Port
Side Wall Service Taps
Standard gas tap and vaccum tap, optional compressed air tap and water tap
Standard gas tap and vaccum tap, optional compressed air tap and water tap
Standard gas tap and vaccum tap, optional compressed air tap and water tap
Antimicrobial Powder Coating
Optional
Optional
Optional
316SS Work Surface
Optional
Optional
Optional
Work Surface
One-piece
One-piece
One-piece
Touch Screen
N
N
N
Motorized Window
Optional
Optional
Optional
Foot Switch
Optional
Optional
Optional
Armrest
Y
Y
Y
Exhaust Duct Connection Kits
Optional
Optional
Optional
Others
Certification
CE, UKCA,TUV
CE, UKCA,TUV
CE, UKCA,TUV
