Teknik Özellikler

Model Number
MDF-DC500VX-PE
External dimensions (W x D x H)
mm
2010 x 845 x 1070
Internal dimensions (W x D x H)
mm
1190 x 640 x 756
Volume
litres
575
Net Weight
kg
328
Capacity
2” boxes
416
Performance
Cooling performance 2)
°C
-86
Temperature setting range
°C
-50 to -90
Temperature control range 2)
°C
-50 to -86
Control
Controller
Microprocessor, non-volatile memory
Display
LCD Touch Screen
Temperature sensor
Pt-1000
Refrigeration
Refrigeration system*
Independent Dual-Cooling
Compressors
W
2 x 1100
Refrigerant
MU-NC500
MU-NC700
Refrigerant weight
g
515
550
GWP of refrigerant for each cooling circuit
5139
5370
Total Refrigerant weight (CO₂ equivalent)
t
5.293
5.907
Insulation material
PUF / VIP Plus
Insulation thickness
mm
70/135
Construction
Exterior material
Painted Steel
Interior material
Stainless Steel
Outer lid
qty
1
Outer lid lock
Y
Inner lid
3 pieces (Styrofoam)
Access Port
qty
1
- position
Back
- diameter
Ø mm
17
Alarms (R = Remote Alarm, V = Visual Alarm, B = Buzzer Alarm)
Power failure
V-B-R
High temperature
V-B-R
Low temperature
V-B-R
Filter
Filterless design
Lid open
V-B
Electrical and Noise Level
Power supply
V
230
Frequency
Hz
50
Noise level3)
dB [A]
52
Options
Liquid CO2 back-up
MDF-UB5-PW
Temperature recorders
- Circular type
MTR-G85C-PE
- Chart paper
RP-G85-PW
- Ink pen
PG-R-PW
- Continuous strip type
MTR-85H-PW
- Chart paper
RP-85-PW
- Ink pen
DF-38FP-PW
- Recorder housing
MDF-S3085-PE
