Teknik Özellikler

Model MDF-U731M-PE
External dimensions (W x D x H) mm 770 x 830 x 1955
Internal dimensions (W x D x H) mm 650 x 700 x 1520
Volume liters 690
Net weight kg 152
Capacity 2” box 384
Performance
Cooling performance °C -30
Temperature setting range °C -18 to -35
Temperature control range °C -20 to -30
Control
Controller   Microprocessor, non-volatile memory
Display   LED
Temperature sensor   Thermistor
Cooling
Cooling system   Direct
Compressors W 400
Refrigerant   R-290
Refrigerant charge g 110
Refrigerant GWP per cooling circuit   3
Total refrigerant charge (CO₂ equivalent) t 0.000
Insulation material   PUF
Insulation thickness mm 60
Construction
Exterior material   Painted steel
Interior material   Painted steel
Outer door pcs 1
Outer door lock   Yes
Inner doors pcs -
Shelves pcs 4
Maximum load - per shelf kg 50
Maximum load - total kg 200
Access port pcs 1
Position   Left
Diameter Ø mm 30
Casters pcs 4 (2 leveling feet)
Alarms (R = Remote alarm, V = Visual alarm, B = Buzzer alarm)
Power failure   V-B-R
High temperature   V-B-R
Low temperature   V-B-R
Door open   V-B
Electrical and Noise Level
Power supply V 230
Frequency Hz 50
Noise level dB [A] 42
Options
Storage containers   MDF-T07SC-PW (set of 2)
Additional shelves   MDF-T07ST-PW (set of 3)
Temperature recorders (circular type)   MTR-G85C-PE
Chart paper   RP-G85-PW
Ballpoint pen   PG-R-PW
Recorder housing   MPR-S7-PW
Continuous strip type   MTR-4015LH-PE
Chart paper   RP-40-PW
Recorder housing   MPR-S30-PW
