Teknik Özellikler

Model MDF-DU300H-PE
Dimensions
External dimensions (W x D x H) mm 750 x 870 x 1830
Internal dimensions (W x D x H) mm 490 x 600 x 1140
Volume liters 333
Net weight kg 241
Capacity 2” Boxes 216
Performance
Cooling performance °C -86
Temperature setting range °C     -50 to -90
Temperature control range °C  -50 to -86
Control
Controller Microprocessor controlled
Display LED
Temperature sensor Pt-1000
Cooling
Cooling system Cascade
High-stage compressor W 450
High-stage refrigerant HC
Low-stage compressor W 450
Low-stage refrigerant HC
Insulation material PUF
Insulation thickness mm 130
Construction
Outer material Painted Steel
Inner material Painted Steel
Outer door pcs 1
Outer door lock Available
Inner doors pcs 2 (insulated)
Shelves pcs 3
Maximum load per shelf kg 50
Total maximum load 3) kg 150
Access Port pcs 3
position rear/bottom x 2
diameter Ø mm 17
Casters pcs 4 (2 leveling feet)
Alarms (V = Visual Alarm, B = Buzzer Alarm, R = Remote Alarm)
Power failure V-B-R
High temperature V-B-R
Low temperature V-B-R
Filter V-B
Electrical and Noise Level
Power supply V 230V 50Hz
Noise level dB [A] < 52
Options
Liquid CO2 backup CVK-UB2-PW
Temperature recorders
Circular type MTR-G85C-PE
Chart paper RP-G85-PW
Ballpoint pen PG-R-PW
Continuous chart type MTR-85H-PW
Chart paper RP-85-PW
Ballpoint pen DF-38FP-PW
Recorder cover MDF-S3085-PW
Drawers MDF-30R-PW (max 2)
