Teknik Özellikler

Model MDF-DC700VX-PE
External dimensions (W x D x H) mm 2300 x 845 x 1070
Internal dimensions (W x D x H) mm 1480 x 640 x 756
Volume litres 715
Net weight kg 358
Capacity 2” boxes 520
Performance
Cooling performance °C -86
Temperature setting range °C  -50 to -90
Temperature control range °C -50 to -86
Control
Controller Microprocessor, non-volatile memory
Display LCD Touchscreen
Temperature sensor Pt-1000
Refrigeration
Refrigeration system Independent dual refrigeration
Compressors W 2 x 1100
Refrigerant MU-NC500 MU-NC700
Refrigerant charge g 515 550
Refrigerant GWP per refrigeration circuit 5139 5370
Total refrigerant charge (CO₂ equivalent) t 5.293 5.907
Insulation material PUF / VIP Plus
Insulation thickness mm 70/135
Construction
Outer material Painted steel
Inner material Stainless steel
Outer door pcs 1
Outer door lock Yes
Inner door 3 sections (Foam)
Access port pcs 1
 - location Rear
 - diameter Ø mm 17
Alarms (R = Remote Alarm, V = Visual Alarm, B = Buzzer Alarm)
Power failure V-B-R
High temperature V-B-R
Low temperature V-B-R
Filter Filterless design
Door open V-B
Electrical and Noise Level
Power supply V 230
Frequency Hz 50
Noise level dB [A] 52
Options
Liquid CO2 backup MDF-UB5-PW
Temperature recorders
 - Circular type MTR-G85C-PE
 - Chart paper RP-G85-PW
 - Ballpoint pen PG-R-PW
 - Continuous strip type MTR-85H-PW
 - Chart paper RP-85-PW
 - Ballpoint pen DF-38FP-PW
 - Recorder case MDF-S3085-PE
